TYPICAL VALUES Models 58D and 58M

Model

number

Output

V/A

RECTANGULAR PULSE

SINEWAVE

DC saturation current Isat A

Max rms current Irms A

Peak current Ipeak A

Price GPB

*

Droop %/ms

Rise time ns

I-t Capability

3db Bandwidth

Ipeak/f A/Hz

No bias mA s

With bias   mA s

lf Hz

hf MHz

58EH010

0.010

0.38

80

13000

24000

0.5

5

85

55

400

25000

POA

58E0020

0.020

0.6

200

12000

20000

0.8

2

70

55

500

20000

POA

58M0020

0.020

0.04

200

12000

20000

0.06

2

70

2.0

500

20000

POA

58E0050

0.050

1.5

80

3400

6000

2.5

5

20

55

200

10000

POA

58M0050

0.050

0.1

80

3400

6000

0.15

5

20

2.0

200

10000

POA

58E0100

0.10

6

40

1000

1800

10

10

6.0

55

100

5000

POA

58EH100

0.10

15

20

400

700

20

20

2.0

55

100

2500

POA

58M0100

0.10

0.3

40

1000

1800

0.5

10

6.0

2.0

100

5000

POA

58MH100

0.10

1.0

20

400

700

1.0

20

2.0

2.0

100

5000

POA

58E0200

0.20

25

20

200

360

40

20

1.0

55

50

2500

POA

58M0200

0.20

2

20

200

360

4

20

1.0

2.0

50

2500

POA

58M0500

0.50

9

20

40

70

15

20

0.2

2.0

20

1000

POA

58M1000

1.0

30

14

10

18

40

30

0.06

2.0

12

500

POA

58M5000

5.0

800

14

0.4

0.7

1500

30

0.002

2.0

2

100

POA
